Kenmerken:
Automatische 800 VA noodstroomvoorziening
Automatische AC spanningsregelaar en stabilisator (AVR)
Intelligente beveiliging tegen spanningspieken, overbelasting en kortsluiting
Hoorbaar en zichtbaar alarm bij stroomuitval
LED statusindicatie
Interne batterij met bescherming tegen overladen of teveel ontladen
Mogelijkheid voor muurbevestiging
Specificaties:
Type: line interactive
Waveform: sine wave (AC mains), modified (square) sine wave (battery)
Input: 220 V AC ± 25%, 50 / 60 Hz ± 10%
Output: 220 V AC ± 10%, 50 / 60 Hz ± 1% (220 V AC ± 5 % at inverter mode)
Switching time: less than 12 ms
Backup time: 10...30 mins (depends on the load)
Battery: sealed lead-acid 12 V DC / 8Ah x 1 pc
Charge time: up to 8 hours
Input: built-in Schuko plug cable, 1.2 m
Sockets: 3 pcs x Schuko output
Operating conditions: 0°C~40°C, at humidity 5~90%RH non condensing
Power: 800 VA (480 W)
Noise: < 45 dB at 1 m distance
Dimensions: 175 x 255 x 93 mm
Product weight: 5.2 kg
''Cold-start'' function
Systemeisen:
In order to work correclty, the connected load should be at least 5% of the maximum capacity of the UPS. For example, a 700 W UPS needs at least a connected load of 35 W to work.
Inhoud:
UPS
Handleiding
