Description You can use this active antenna for your GNSS equipment to receive GPS and BeiDou (COMPASS) signals simultaneously.
Specification • External active additional antenna for GNSS receivers
• Connector: SMA plug
• Polarisation: RHCP
• Frequency range:
GPS: 1575.42 MHz +/- 3 MHz
BeiDou: 1561.098 MHz +/- 5 MHz
• Patch antenna: 3 dBic
• Patchantenne: 25 x 25 x 6 mm
• VSWR: < 1.5
• Axial Ratio: 3 dB
LNA
• Gain: 28 dB
• VSWR: < 2.0
• Impedance: 50 Ohm
• Operating voltage: 3.0 ~ 5.0 V
• Current consumption: 10 ~ 20 mA
• Operating temperature: -40 °C ~ 85 °C
• Protection class: IP65
• Weigth: 0.150 kg
• Cable type: RG174
• Cable diameter: ca. 2.5 mm
• Cable colour: black
• Cable length incl. connector: 3 m
• Dimensions (LxWxH): ca. 5.00 x 4.25 x 1.65 cm
• Magnetic housing bottom
• Material: ABS
System requirements • GNSS device with SMA jack
Package content
• GNSS antenna
