This cassette by Delock is equipped with an MPO male port and twelve LC Duplex female ports and is suitable for installation in 19″ fiber optic HD (High Density) patch panel by Delock (66924). The cassette contains a pre-assembled cabling system, so that the optical fiber signal can be transmitted to different network devices such as switches.
Specification• Connectors:
1 x MPO female >
12 x LC Duplex female
• For 24 Single-mode fibers
• Zirconia ceramic ferrule with protection cap
• For mounting in 19″ fiber optic HD (High Density) patch panel, 1U
• Tool-free installation
• Fibre: 9/125 µm
• Polarity A
• Insertion loss < 0.7 dB (MPO), < 0.2 dB (LC)
• Return loss > 60 dB (MPO), > 60 dB (LC)
• Housing material: metal
• Housing colour: black
• Dimensions (LxWxH): ca. 125 x 102 x 29 mm
• 19″ fiber optic HD (High Density) patch panel
Package content
• Fiber optic HD (High Density) cassette
